Specification

Rated voltage: AC100V～240V 50/60Hz

Input power: 1500W

Light source specifications: 37 40W four-in-one LED Osram light source

Approved life: 30,000 hours

Color: red, green, blue and white, multiple colors

Focus: 2°-60° DMX linear adjustment Focus, with automatic focusing function.

Color temperature control: built-in CTO DMX linear dimming

Electronic strobe: 0.3~25 times/second, synchronous or asynchronous random strobe dimming can be selected: electronic

dimming: 0~100% linear adjustment, with gamma Horse-curve dimming frequency is adjustable from 1.2K to 25K, with macro dimming linear stability and smoothness without flickering. It adopts stable constant current drive and power supply, suitable for video shooting.

Rotation angle: XY axis is driven by a high-speed silent 60 thickened three-phase motor, equipped with a high-precision imported magnetic encoding positioning device to make the operation positioning more accurate. It can automatically return to the position after a malfunction, and the horizontal and vertical speeds are adjustable; the XY axis rotation function and the inversion function are 540° in the horizontal direction (16-bit precision scanning ), 270° in the vertical direction (16-bit precision scanning)

Control mode: 22 (simplified) 22CH/36CH/22+111CH/22+148CH/36+111CH/36+148CH (standard) 6 channel control modes, standard DMX512 protocol , RDM protocol

Control interface: DMX512 interface (3 core/optional 5 core), power cord hand-in-hand socket sleep function: using advanced technology to achieve remote sleep function, when the lamp disconnects the signal, it automatically enters the sleep state, making the lamp more efficient, stable, and safer

Display function: 2.8-inch touch screen, Chinese and English bilingual menu, sensor fault display, temperature display

Cooling system: using high-conductivity copper tube radiator, fan intelligent monitoring technology automatically adjusts the fan rotation speed according to the temperature of the lamp, built-in overheating protection Intelligent system/intelligent temperature and noise balance module

Protection level: IP22

Lighting packaging: waterproof and shockproof flight case or carton

Net weight: 35kg

Product size:

Effect mode: (vortex, kaleidoscope, dyeing, beam) Front mirror plate can be rotated continuously, seamlessly spliced ​​mirror plate, aspherical lens structure, single lamp bead point control light strip effect: strobe, horse racing effect, with built-in program

Features

1. Automatic screen rotation function, the system can automatically rotate the screen according to the direction of gravity, no manual rotation required! You can also turn off the auto-rotation feature
